Encapsulation start up transformer

LEABE QOSC Series Encapsulation Start-Up Transformer Product Overview LEABE introduces the QOSC Series Encapsulated Transformer, a premium Motor Starting Transformer designed for the rigorous demands of large AC asynchronous motors. When started at full voltage, motors can draw 5–7 times their rated current, causing significant voltage dips and mechanical stress on the power grid. Our Start Autotransformer employs advanced epoxy resin encapsulation to deliver reduced voltage during startup, effectively balancing high breakaway torque with minimized line disturbances. Unlike conventional dry-type units, the fully encapsulated design provides superior protection against environmental contaminants, making it ideal for harsh industrial settings. Covering a power range from 220 kW to 20000 kW, this LEABE Transformer ensures reliable, high-performance motor starting for the world’s most demanding applications. Technical Specifications The QOSC series is engineered for robustness and prec…
